Wine-Mate 1500SSW Split Wall-Recessed Wine Cooling System

Wine-Mate 1500SSW Split Wall-Recessed Wine Cooling System
SKU: WM-1500SSW
$6,445.00
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

The Wine~Mate 1500SSW cooling unit is a split system design with a capacity of 150 cubic feet. Split cooling systems consist of an evaporator unit and a remote condensing unit; they are connected by a liquid line and an insulated suction line. Condensing units can be located away from the wine cellars up to 75 ft to isolate compressor noise and vibration. SSW evaporator/fan units have a special coil coating. Split cooling systems are designed to provide a subtle temperature between 50~65 °F for a properly insulated wine cellar. The humidity range of the refrigerated space can be maintained within 50~75% RH. These temperature and humidity ranges are optimized for long term storage of wine like that in natural caves. The SSW series was designed to be wall-mounted and can be installed between two wall studs, making them an ideal choice for small and medium wine rooms.

Wine~Mate cooling systems are also perfect for storing fine fur, cigars, leather goods, chocolate and salami! For an additional cost, Wine~Mate systems can be customized for your exact storage needs - please call for more information!

  • SPLIT SYSTEM COOLING UNIT – Wall-Recessed Wine Cooling System
  • SSW cooling systems consist of a remote condensing unit and an evaporator unit and they are connected by a liquid line and an insulated suction line.
  • SSW evaporator/fan units can be installed inside a wine rack or between two wall studs, making them an ideal choice for wine cabinets or small wine rooms as built-in installation.
  • SSW evaporator/fan units have a special coil coating.
  • SSW condensing units can be located away from the wine cellar up to 75 ft so that noise and compressor vibrations are isolated.
  • SSW condensing units shall not be exposed to temperatures higher than 110°F or lower than 50°F.
  • If the exhaust ambient temperature exceeds 110 °F, one size larger unit must be used.
  • Low ambient kit for below 50°F cold weather operation
  • TEMPERATURE: The WM-1500SSW cooling unit is designed to provide a subtle temperature between 50~65 °F for a properly insulated wine cellar.
  • AMBIENT TEMPERATURE RANGE: The ambient temperature range for WM-1500SSW should not exceed the temperature of the cellar by more than 25°F. Cellar walls should not receive direct sun or strong wind. Lighting should be low wattage and installed on a timer to ensure that lights are not left on when the cellar is unoccupied.
  • HUMIDITY CONTROL: The refrigerated space will maintain humidity within the range of 50~75% RH. We use an innovative method to provide additional humidity.
  • DISPLAY: Digital display with easy push-button controls
  • NOTIFICATIONS: Display notifications provide alerts help to protect your wine cellar and alert you when maintenance is required.
  • CONTROL PANEL: Control panel includes digital display, manual defrost button, up and down arrows to adjust temperature as well as browse parameters, power button, and SET button.
  • Outdoor enclosure is included with condensing unit
  • WARRANTY: 1-year warranty on parts, 1-year labor.

NOTE: Split systems must be installed by a certified refrigeration technician. Purchase does not include the copper tubing.
Wine-Mate split cooling systems use EC fan motors that meet federal regulation of 10 CFR 431.306 and are required by the federal law.

The Wine~Mate 1500SSW cooling unit is a split system design with a capacity of 150 cubic feet. Split cooling systems consist of an evaporator unit and a remote condensing unit; they are connected by a liquid line and an insulated suction line. Condensing units can be located away from the wine cellars up to 75 ft to isolate compressor noise and vibration. SSW evaporator/fan units have a special coil coating. Split cooling systems are designed to provide a subtle temperature between 50~65 °F for a properly insulated wine cellar. The humidity range of the refrigerated space can be maintained within 50~75% RH. These temperature and humidity ranges are optimized for long term storage of wine like that in natural caves. The SSW series was designed to be wall-mounted and can be installed between two wall studs, making them an ideal choice for small and medium wine rooms.

Wine~Mate cooling systems are also perfect for storing fine fur, cigars, leather goods, chocolate and salami! For an additional cost, Wine~Mate systems can be customized for your exact storage needs - please call for more information!

  • SPLIT SYSTEM COOLING UNIT – Wall-Recessed Wine Cooling System
  • SSW cooling systems consist of a remote condensing unit and an evaporator unit and they are connected by a liquid line and an insulated suction line.
  • SSW evaporator/fan units can be installed inside a wine rack or between two wall studs, making them an ideal choice for wine cabinets or small wine rooms as built-in installation.
  • SSW evaporator/fan units have a special coil coating.
  • SSW condensing units can be located away from the wine cellar up to 75 ft so that noise and compressor vibrations are isolated.
  • SSW condensing units shall not be exposed to temperatures higher than 110°F or lower than 50°F.
  • If the exhaust ambient temperature exceeds 110 °F, one size larger unit must be used.
  • Low ambient kit for below 50°F cold weather operation
  • TEMPERATURE: The WM-1500SSW cooling unit is designed to provide a subtle temperature between 50~65 °F for a properly insulated wine cellar.
  • AMBIENT TEMPERATURE RANGE: The ambient temperature range for WM-1500SSW should not exceed the temperature of the cellar by more than 25°F. Cellar walls should not receive direct sun or strong wind. Lighting should be low wattage and installed on a timer to ensure that lights are not left on when the cellar is unoccupied.
  • HUMIDITY CONTROL: The refrigerated space will maintain humidity within the range of 50~75% RH. We use an innovative method to provide additional humidity.
  • DISPLAY: Digital display with easy push-button controls
  • NOTIFICATIONS: Display notifications provide alerts help to protect your wine cellar and alert you when maintenance is required.
  • CONTROL PANEL: Control panel includes digital display, manual defrost button, up and down arrows to adjust temperature as well as browse parameters, power button, and SET button.
  • Outdoor enclosure is included with condensing unit
  • WARRANTY: 1-year warranty on parts, 1-year labor.

NOTE: Split systems must be installed by a certified refrigeration technician. Purchase does not include the copper tubing.
Wine-Mate split cooling systems use EC fan motors that meet federal regulation of 10 CFR 431.306 and are required by the federal law.
