The WhisperKOOL Ductless Wall Mount Platinum Split Series is a premium climate control system designed to maintain wine cellars at a precise 55°F with 60% to 70% humidity. By separating the indoor evaporator from the condenser, this system eliminates noise and vibration within the cellar. Units are available through the wall.
Available Models & Sizing
Model selection depends on your cellar’s cubic footage and thermal factors, such as glass walls:
- Platinum Mini Split: Up to 500 cu. ft.
- Platinum Split 4000: Up to 1,000 cu. ft.
- Platinum Split 8000: Up to 1,750 cu. ft.
- Platinum Split 9000 Twin: For high-capacity or commercial spaces.
Core Features
- Pump-Down Cycle: Protects and extends compressor life.
- Liquid Sensing Bottle Probe: Monitors actual liquid temperature to prevent short-cycling.
- Advanced Digital Controls: Remote KDT Electronic Display for temperature management and alarms.
- Flexible Placement: The condenser can be installed up to 100 line feet away.
- Smart Home Integration: Optional 24V thermostat conversion available.
Condenser Comparison
Each unit must be paired with one of two specialized condensers:
- Omega 110V: Standard residential setups.
- 220V High-Efficiency: Uses up to 50% less energy, ideal for warm climates.
Installation Requirements
- Professional Installation: A certified HVAC-R technician is required for refrigerant charging and brazing. DIY installation voids the warranty.
- Insulation: The room must have a vapor barrier and at least R-13 insulation (R-19 preferred).
- Placement: The evaporator must be mounted within 18 inches of the ceiling for optimal air distribution.
To help determine the best model for your needs, please provide the total cubic feet of your cellar and let us know if it includes any glass walls or doors?
